12kW Hybrid Solar Inverter Three Phase Low Voltage 10yrs Warranty

Product information

Wattage:

  • Max. usable PV input power: 19.2kW;
  • Rated output power AC: 12kW

Current:

  • Max. input current: 20A / 40A
  • Max. short circuit current: 30A /50A;
  • Max. output current: 18.2A / 17.3A;
  • Rated grid output current: 18.2A / 17.3A;

Voltage:

  • Max. PV Input DC Voltage: 1000V;
  • MPPT Range: 200~850V;
  • Rated PV Input DC Voltage: 550V;
  • Start-up Voltage: 160V;

Frequency: Rated grid frequency: 50 Hz

Power Factor: >0.99 (0.8 leading – 0.8 lagging)

IP Rating: IP66

Working conditions: -40~+60℃

Size:  430 × 660 × 295 mm

Order code: 12228

Product code: S6-EH3P12K02-NV-YD-L

Item Weight: 42 kg

Items per pack: 1

Release Date: 31.10.2024

Brand: Solis

Warranty: 10 years
