20kW Hybrid Solar Inverter Three Phase High Voltage

Product information

Wattage:

Max. PV Input Power: 26000W;
Rated AC Input/Output Active Power (W): 20000W;
Peak Power (off-grid) (W): 1.5 times of rated power, 10s;

Current:

Max. Operating PV Input Current (A) 26+26
Max. Input Short-Circuit Current (A) 39+39;
Rated AC Input/Output Current (A) 30.4/29;
Max. AC Input/Output Current (A) 33.4/31.9;

Frequency: Rated Input/Output Grid Frequency/Range(Hz) 50/45-55, 60/55-65

Power Factor: 0.8 leading to 0.8 lagging

IP Rating: IP65

Working conditions: -40~60℃ BJ2, >45℃ Derating

Size: 408 x 638 x 237mm

Order code: 12170

Product code: SUN-20K-SG01HP3-EU-AM2

Item Weight: 30.5 kg

Items per box: 1

Items per pack: 1

Release Date: 10.06.2024

Brand: Deye

Warranty: 10 years
