Product information

Wattage:

• Max. Input Power: 7800W;
• Rated AC Output and UPS Power: 6000W;
• Max. AC Output Power: 6600W;

Current:

•  PV Input Current: 13A+13A ;
• AC Output Rated Current: 9.1/8.7A;
• Max. AC Current: 10/9.6A;
• Max. Three-phase Unbalanced Output Current: 13.6/13A;
• Max Output short circuit current: 75A;
• Max. Continuous AC Passthrough: 45A;

Frequency: Output Frequency 50/60Hz

Power Factor: 0.8 leading to 0.8 lagging

IP Rating: IP65

Working conditions: -40~60℃ BJ2, >45℃ Derating

Size: 330 × 580 × 232 mm

Order code: 11788

Product code: SUN-6K-SG04LP3-EU

Item Weight: 33.6 kg

Items per box: 1

Release Date: 03.05.2023

Brand: Deye

Warranty: 10 years
